API 5L Gr.B Seamless Pipe, 3 Inch, 6M, SCH 40, BE
Key Specifications / Features
Model No.: DB-CS-SMLS-6 Hits: 36
China API 5L Gr.B SAW Line pipe Manufacturer Grit offers API 5L Gr.B Seamless Pipe, 3”, SCH.40, API 5L-2009, ISO 3183-2007, Black Paint, 6M.
Request a quote
Share
Tags:
Detail Infomation
Type: API 5L Gr.B Seamless Pipe.
Material: API 5L Gr.B.
OD: 3”
W.T: SCH.40.
Length: 6M.
Standard: API 5L-2009, ISO 3183-2007.
Ends: BE.
Surface Treatment: Black Painting.
Material: API 5L Gr.B.
OD: 3”
W.T: SCH.40.
Length: 6M.
Standard: API 5L-2009, ISO 3183-2007.
Ends: BE.
Surface Treatment: Black Painting.
| Tolerance for wall thickness: | |
| Wall thickness t mm(in) |
Tolerances mm(in) |
| SMLS pipe | |
| ≤4.0（0.157） | +0.6(0.024) |
| +0.5(0.020) | |
| ＞4.0（0.157） to ＜25.0（0.984） | +0.150 t |
| -0.125 t | |
| ≥25.0（0.984） | +3.7(0.146) or 0.1 t,whichever is the greater |
| -3.0(0.120) or -0.1 t,whichever is the greater | |
| Welded pipe | |
| ≤5.0(0.197) | ±0.5(0.020) |
| ＞5.0(0.197) to＜15.0(0.591) | ±0.1 t |
| ≥15.0(0.591) | ±1.5(0.060) |
| Chemical Composition and Mechanical Property For PSL .1 | |||||||||||||||
| Steel Grade | Chemical components | Mechanical performance | |||||||||||||
| C(Max) | Mn(Max) | P | S(Max) | Tensile strength(Min） | Yield Strength (Min) |
||||||||||
| Min. | Max. | psi | Mpa | psi | Mpa | ||||||||||
| Seamless Pipe | |||||||||||||||
| B | 0.28 | 1.20 | / | 0.030 | 0.030 | 60200 | 415 | 35500 | 24 | ||||||
